Embedded Systems & Firmware Development

Image Placeholder

A) A Background

1. UNIX, POSIX, Linux, and the ABI/API stack

In the 1970s, UNIX was created at Bell Labs as a small, elegant OS meant to be built upon, but licensing led to forks (BSD, System V, etc.) and fragmentation. This drove IEEE's POSIX effort in the 1980s to standardize a common API across UNIX-like systems. The GNU project aimed to build a free UNIX replacement but lacked a kernel — Linus Torvalds' 1991 Linux kernel filled that gap, and because it closely follows POSIX, it supports portable UNIX applications and became the heart of modern open-source OSes.

Linus Torvalds

Linus Torvalds : The developer of LINUX

The Linux kernel manages hardware and processes and exposes system calls (open, read, fork, exec, ...) which form the ABI (Application Binary Interface — binary-level contract). The POSIX API defines a consistent source-level interface (fopen, pthread_create, ...). libc (glibc/musl) sits between applications and the kernel, translating POSIX calls into actual syscalls via the correct ABI — enabling portability across hardware and kernel versions as long as the ABI is stable.

2. Linux Filesystem Principles

Inodes: every file has an inode storing metadata (size, permissions, timestamps, owner, pointers to data blocks) — not the filename.
Filename ↔ inode mapping: directories map names to inode numbers, so multiple names (links) can point to one inode.
Blocks: storage is divided into blocks (512B–4KB); inodes point to these blocks (direct, indirect, double indirect, etc.).
Hard links: a second directory entry pointing to the same inode; data persists until the last link is deleted.
Symlinks: a special file containing a path to another file, with its own inode; can cross filesystems or point to nothing (broken link).
Directories: special files listing filenames → inode numbers, making rename/move fast (just a directory-entry change).
Everything is a file: devices, sockets, pipes, directories all share the file interface.
Mounting: filesystems (ext4, vfat, ntfs, ...) mount into the unified tree at /, or subdirectories like /mnt, /home.
Permissions: inode permission bits + ownership control access via the kernel.
Filenames are independent of inodes (up to ~255 chars, reusable across dirs).
Keeping filenames out of inodes enables linking, fast lookups, and inode reuse.
Daemon: an application that runs in the background.

3. Commands

Command	Purpose
`cp source target`	copy files/dirs (`-r` for directories)
`mv source target`	move or rename
`rm file`	remove (`-r` dirs, `-f` force)
`touch filename`	create empty file / update timestamp
`cat file`	print contents; `cat file1 file2` to combine
`less file`	page through a file (`q` to quit)
`head -n 10 file`	first 10 lines
`tail -n 10 file`	last 10 lines
`grep "pattern" file`	search pattern (`-r` recursive)
`find path -name filename`	search by name
`which command`	path of an executable
`ps aux`	list running processes
`kill PID`	signal a process (`-9` force)
`top` / `htop`	live CPU/memory view
`df -h`	disk space, human-readable
`du -sh folder`	total size of a folder
`chmod +x file`	make executable
`chown user:group file`	change ownership
`tar -czvf archive.tar.gz folder/`	compress
`tar -xzvf archive.tar.gz`	extract
`scp file user@host:/path`	secure copy to remote
`wget URL`	download a file
`curl -O URL`	download / send requests
`man command`	manual page
`sudo command`	run as root
`pacman -S/-R/-Ss package`	install / remove / search (Arch)
`journalctl -xe`	view system logs
`systemctl status/start/stop/restart service`	manage a systemd service

Shell operators

| pipe — send output of one command as input to another, e.g. ls | grep file
> redirect (overwrite), >> redirect (append)
< redirect input from a file
&& run next only if previous succeeds
|| run next only if previous fails

Paths

Relative: ./folder/file.txt, ../file.txt
Absolute: /home/user/docs
~ home dir, . current dir, .. parent dir

4. Sysroot & Cross-Compilation

A sysroot mimics a target device's / on the development machine, used during cross-compilation so the compiler knows where to find target headers/libs. Cross-compilation is needed when building for a different architecture than the host (e.g., ARM target, x86 dev machine).

Typical sysroot layout:

sysroot/
├── bin/               # Essential binaries (ls, bash, etc.)
├── boot/              # Boot files (optional in sysroot)
├── dev/               # Device nodes (usually not needed)
├── etc/               # Config files (/etc/resolv.conf, /etc/hostname)
├── home/
│   └── user/
├── lib/               # Core shared libraries (.so)
├── lib64/
├── media/ mnt/        # Mount points
├── opt/               # Optional packages (e.g. TensorRT, OpenCV)
├── proc/              # Kernel interfaces (not needed in sysroot)
├── root/
├── run/ sbin/ srv/ sys/ tmp/
├── usr/
│   ├── bin/ lib/ include/ share/
├── var/
│   ├── log/ tmp/ lib/
└── workspace/

Naming conventions: shared libs libXYZ.so, libXYZ.so.1.2, libXYZ.a; headers match lib name (xyz/xyz.h); app binaries in /usr/bin/ or /opt/my_app/bin/; optional packages in /opt/; configs in /etc/my_app/; models/assets in /opt/my_app/models/ or /usr/share/my_app; logs to /var/log/my_app/.

Practical example — cross-compiling an OpenCV + TensorRT app for a Jetson Nano:

sysroot/
├── lib/libc.so.6
├── usr/
│   ├── include/opencv4/
│   ├── lib/libopencv_core.so, libtensorrt.so
│   └── bin/smartcam-app
├── etc/smartcam/config.yaml
├── opt/smartcam/
│   ├── models/yolov5.engine
│   └── assets/overlay.png
└── var/log/smartcam.log

5. Static vs Dynamic Linking

Static: library code is copied into the binary — fast, portable, larger file size.
Dynamic: links to .so (shared object) files loaded at runtime — smaller size, needs the .so present at runtime.
Static libs live at /usr/lib/libxyz.a; dynamic libs at /usr/lib/libxyz.so.

6. Linux File Extensions

Ext	Meaning
`.sh`	Shell script (Bash/other)
`.c` `.cpp` `.h`	C/C++ source/header
`.py`	Python script
`.out`	Default gcc executable name
`.so`	Shared object (dynamic lib, like `.dll`)
`.a`	Static library (linked at compile time)
`.o`	Object file (pre-link intermediate)
`.ko`	Kernel object (kernel module)
`.tar` `.tar.gz` `.tgz`	Archives
`.gz` `.xz` `.bz2`	Compressed files
`.deb` `.rpm`	Package formats (Debian/Red Hat)
`.iso`	Disk image
`.service`	systemd service file
`.desktop`	GUI app shortcut
`.conf`	Config file
`.log`	Log file
`.img` `.bin` `.elf`	Binary/firmware images
`.AppImage`	Portable Linux app
`.run`	Installer/auto-install script
`.md` `.txt` `.rst`	Documentation

B) C Programming

Important: shell scripts need a shebang (#!/bin/bash or #!/bin/sh) as the first line, matching the target shell — emulated QEMU terminals often use sh, not bash.

7. Toolchain = compiler + linker + assembler + tools. E.g. aarch64-linux-gnu-gcc bundles gcc/g++, gdb (debugger), ld (linker), addr2line, objdump (disassembler), strip (remove debug info / compress binary), readelf.

a. Makefile syntax

all: $(TARGET)
$(TARGET): $(SRC)
	$(CC) $(CFLAGS) -o $(TARGET) $(SRC)
clean:
	rm -f $(TARGET) *.o

CC: compiler command (gcc for x86, aarch64-linux-gnu-gcc for ARM)
CFLAGS: -Wall (show all warnings), -Werror (treat warnings as errors), -g (include debug info)
TARGET: output binary name; SRC: source files
all: and clean: are conventional targets for make / make clean

b. Embedded C concepts

i. Embedded C code has 4 main parts: headers, initialization, main loop, interrupts.

ii. Avoid int/float/double — use fixed-size types (uint8_t, uint16_t, int16_t, ...). Memory is often shown in hex (0x00–0xFF).

iii. Memory segments:

Initialized globals → .data
Uninitialized globals → .bss
Local variables (auto) → .stack
malloc'd variables → .heap (manual alloc/free, avoid unless needed for variable-sized buffers)
static variables → .data
const variables → .rodata
Actual code → .text

iv. The compiler assumes a variable won't change externally unless declared volatile — essential when interrupts, hardware peripherals, or other threads can modify memory, e.g. volatile int flag = 0; checked inside while (flag == 0).

v. Hardware registers (GPIO, UART) are memory-mapped:

#define GPIO_REG (*((volatile uint32_t*)0x50000000))
GPIO_REG |= (1 << 5);   // Set bit 5 high (turn on LED)
GPIO_REG &= ~(1 << 5);  // Clear bit 5 (turn off LED)

Operation	Code	Purpose
Set bit	`x	= (1<<n)`
Clear bit	`x &= ~(1<<n)`	Disable pin/feature
Toggle	`x ^= (1<<n)`	Flip LED state
Check	`x & (1<<n)`	Read input/flag

Struct-based peripheral access:

typedef struct {
	volatile uint32_t DATA;
	volatile uint32_t DIR;
	volatile uint32_t MODE;
} GPIO_TypeDef;

#define GPIOA ((GPIO_TypeDef*)0x50000000)

GPIOA->DIR |= (1 << 2);  // Make pin 2 output
GPIOA->DATA |= (1 << 2); // Set pin high

vi. Polling a volatile variable wastes CPU cycles, so interrupts are used instead — an ISR (interrupt service routine) handles a given interrupt, mapped via an interrupt vector table. ISRs can be nested/prioritized so higher-priority interrupts can preempt lower-priority ones.

vii. MCU serial protocols: UART (logging, GPS, BT — low speed, 2 wires, RX/TX pins, 8 data bits + 1 stop bit, most common), SPI (sensors, flash — high speed, 4+ wires), I2C (sensor networks, RTC — medium speed, 2 wires).

USART_CR1 |= (1 << TE);      // Enable transmitter
USART_BRR  = calculated_baud; // Wrong baud rate → garbled data

// Send one character
while (!(USART_SR & TXE));   // Wait for TX buffer empty
USART_DR = 'A';

while (!(USART_SR & RXNE));  // Wait for data to arrive
char c = USART_DR;

viii. Bitwise ops: <</>> shift left/right. Hex digit = 4 bits, so 2 hex digits = 1 byte.

Set: reg = reg | (1 << 0)
Clear: reg = reg & ~(1 << 4)

C) File Handling

8. fopen is buffered I/O (library wrapper, returns a FILE*), open is a raw syscall (returns an int file descriptor). fopen reduces kernel syscalls since buffering happens in userspace.

int fd = open(const char *pathname, int flags, mode_t mode);
read(int fd, void *buf, size_t count);
write(int fd, const void *buf, size_t count);

mode = user permissions, flags = file permissions (e.g. O_RDWR|O_CREAT, S_IRWXU|S_IRWXG|S_IRWXO). Admins can umask to strip permission bits from newly created files. Permissions as numbers: 4=r, 2=w, 1=x (so 6=rw-, 5=r-x) across user/group/others. umask 0002 strips w from others; umask 0003 strips wx from others.

9. A FIFO (named pipe, made with mkfifo) is first-in-first-out: one process writes, another reads. If no reader, the writer blocks — unless opened with O_NONBLOCK. Pipes use a (typically circular) buffer; if full, the writer waits. poll()/select() check readiness for read/write on files/sockets/pipes. EAGAIN = no data available to read. strace traces syscall interaction with the kernel.

10. write() completing doesn't mean data is on disk — it's in the kernel buffer (risk on unclean shutdown). Use sync, fsync(), fdatasync(), or the O_SYNC flag to force writes to disk before success is reported.

lseek(int fd, off_t offset, int whence) repositions the file offset:

SEEK_SET — use specified offset
SEEK_CUR — increment/decrement from current
SEEK_END — from EOF

lseek moves the shared file position (race-prone with multiple threads); pread/pwrite avoid this:

pread(int fd, void *buf, size_t count, off_t pos); // doesn't change file position

11. Reading multiple file descriptors: either spawn a blocking thread per fd, or use non-blocking, multiplexed I/O with a single thread checking all fds via select(), pselect(), or poll().

D) Process Handling and Kernel

12. The kernel manages processes by PID. Special processes:

idle process (PID 0): power control
init process (PID 1): initializes systems/services/login; all processes descend from it; kernel starts it last in boot. init reads initscripts and launches the rest of the boot sequence.
execl() replaces the current process image with a new one, keeping the same PID/priority/ownership; everything else is replaced. Returns nothing on success.
fork() creates a new child process with a new PID (often used to start daemons); local vars/kernel resources are copy-on-write (only copied when the child actually modifies them).
If a child exits and the parent never wait()s, the child becomes a zombie. wait() retrieves the child's exit code/reason so the parent can check for errors. A full "new process" flow is fork() → execl() → wait().
system() does all three, but risks path injection (e.g. a compromised PATH redirecting ls to a malicious binary instead of /usr/bin/ls).

13. A tty is a terminal I/O device. A process group is a set of processes; a session is a set of process groups (created for a login shell on a tty). & backgrounds a command. Ctrl-C sends SIGINT only to the foreground process group of a session. ps lists processes with CPU/memory/PID/user. A daemon is a background process with no controlling terminal, usually run as root, conventionally named ending in d, and typically forked from init.

Creating a standard daemon: fork from a child of init → exit() in the parent (letting the grandparent/init continue) → setsid() (new session, no controlling tty) → chdir → close fds → redirect stdin/stdout/stderr to /dev/null. Logging frameworks like syslog are used instead of terminal output.

14. The kernel manages resources, interfaces with hardware, and exposes APIs to userspace, running at the highest CPU privilege level. Entry points are syscalls or hardware interrupts.

Processes live in a circular doubly-linked task list, each a struct task_struct (<linux/sched.h>, ~1.7KB on 32-bit) holding open files, address space, pending signals, state, etc. (On some architectures, e.g. x86, it's embedded within thread_info for register/memory handling reasons.)

States: TASK_RUNNING, TASK_INTERRUPTIBLE, TASK_UNINTERRUPTIBLE, TASK_TRACED, TASK_STOPPED (altered via set_task_state()).

Traditional UNIX schedulers use fixed time-slices per process, with priority influenced by a nice value (lower nice = higher priority = larger/more frequent slices) — but mapping nice values to absolute time slices can behave inconsistently.

Linux's Completely Fair Scheduler (CFS) instead models an "ideal, perfectly multitasking processor," proportionally sharing CPU based on nice-derived weight, and always running the process with the smallest virtual runtime next — ensuring fairness and preventing starvation. It uses a targeted latency (total time all runnable processes should run in one period), divided among them, with a minimum granularity (~1ms) to bound context-switch overhead.

15. Kconfig controls kernel configuration, saved to .config at the kernel source root. Drivers can be off/on/module (loadable at runtime). A defconfig provides an initial .config known to work for specific hardware (usually vendor-provided). Kbuild compiles driver Makefiles: obj-y = built into the kernel, obj-$(VAR) = module mode (included via a variable). -j$(nproc) parallelizes the build across cores.

Manual kernel build steps: create out dir → clone stable Linux source → build kernel image into outdir → create rootfs skeleton (bin, dev, etc, home, lib, lib64, proc, sbin, sys, tmp, usr, var) → build & install busybox → get shared libs and program interpreter → make device nodes → chown -R root:root * → create the cpio.gz ramdisk.

E) Threading, Multithreading and Signals

16. Analogy: traditional multithreading = many cooks (threads) working dishes (tasks) in parallel — great with enough CPU cores, but too many cooks causes chaos (context-switch overhead) and pot conflicts (race conditions) over shared data. Node.js's single-threaded event loop is like one smart chef who starts a task (e.g. dough rising = non-blocking I/O) and moves on, returning on a callback — efficient when most work involves waiting, e.g. web servers, and avoids the overhead of many idle-waiting threads.

A thread is the smallest unit of CPU work (e.g. one request/connection). Exiting a process kills all its threads. Linux only supports symmetric multiprocessing (all CPUs share the same RAM) — asymmetric multiprocessing (dedicated RAM per CPU) is much harder to build an OS for.

Unlike Windows, Linux doesn't strongly distinguish threads from processes — each thread gets a normal task_struct, differing only in shared file descriptors/memory:

clone(CLONE_VM | CLONE_FS | CLONE_FILES | CLONE_SIGHAND, 0);

Kernel threads have a NULL mm pointer, can't enter user space, are created only by other kernel threads (often at boot). If a parent exits before its child, the child is reparented to another process in its thread group, or to init.

17. A race condition example: an unprotected increment on a shared variable across threads → inconsistent results (not atomic). An atomic operation is indivisible and appears instantaneous. To make a sequence atomic, use a mutex (mutual exclusion lock) around it.

Other primitives: semaphores and spinlocks. Mutexes/semaphores put waiting threads to sleep; spinlocks busy-wait, used where sleeping isn't allowed (e.g. interrupt contexts).

Mutex: one thread in a critical section at a time; others sleep.
Semaphore: counter-based, can allow N concurrent accesses; common in producer-consumer problems.
Spinlock: like a mutex but busy-waits instead of sleeping — for low-latency/interrupt contexts.
Use mutexes for general locking, semaphores for resource counting, spinlocks for fast atomic ops.

18. Threads waiting on each other → deadlock. Mitigation: lock data (not code), and if multiple locks are needed, always acquire in a consistent order and release in reverse order.

Programs are single-threaded by default; in C use POSIX pthread_create. Unjoined threads don't release resources — leaks if left unjoined. In C++, scoped locks auto-lock/unlock via RAII (Resource Acquisition Is Initialization).

int pthread_create(pthread_t *thread, const pthread_attr_t *attr,
                    void *(*start_routine)(void *), void *arg);

thread: where to store the thread ID (NULL to discard)
attr: stack size / scheduling / detached state (NULL = default)
start_routine: the function to run
arg: argument to that function
Returns 0 on success (nonzero = failure)

int rc = pthread_create(thread_array[thread], NULL, start, &var);

Termination: function returns, pthread_exit(), process exits, or pthread_cancel() from another thread. pthread_join() waits for completion; pthread_detach() un-joins a thread.

19. Signals are stored/processed by the kernel. fork() preserves signal actions; exec() resets them.

Default actions: Term (terminate via SIGTERM), Ign (ignore), Core (SIGTERM + core dump), Stop (SIGSTOP).

Common signals: SIGABRT (assert(), Core), SIGHUP (re-read config on the fly), SIGINT (Ctrl-C), SIGKILL (unconditional, un-ignorable termination), SIGSEGV (segfault, Core), SIGTERM (graceful termination), SIGSTOP (unconditional, un-ignorable stop).

F) Time

20. Time types

i. Wall time: real-world time, HW-managed, updated via network protocol

ii. Process time: time spent executing that process

iii. Monotonic time: system uptime

Absolute time epoch = midnight, Jan 1 1970. The clock updates on ticks/jiffies (64-bit counter), at a HW/platform-dependent frequency (typically 100–1000Hz). time_t (<time.h>) gives seconds since epoch; 32-bit jiffy counters roll over Jan 18 2038. tm is the human-readable form. adjtime slowly walks the clock backward via a daemon to avoid breaking programs relying on absolute time.

sleep() — seconds; returns seconds not slept (due to signal interruption)
usleep() — microseconds; still not signal-precise
nanosleep() — sleep until an absolute time

Sockets can substitute for signals for inter-device TCP/IP communication (including host-forwarding into a QEMU target). Since everything is a file in Linux, sockets are effectively global variables holding a connection's file descriptor.

G) Device Drivers

21. OS structure designs

i. Monolithic (Linux): all apps in user space; VFS, IPC, filesystem, scheduler, VRAM, and drivers all run in kernel space.

ii. Microkernel (FreeRTOS): some OS-level operations run from user level (app IPC, UNIX server, device drivers, file server), while base IPC/VRAM/scheduling stay in kernel space.

iii. Hybrid kernel (Windows, macOS): file server / UNIX server in user space; app IPC, device drivers, and the rest stay in kernel space.

22. Device drivers operate hardware through well-defined abstractions, built separately from the kernel and pluggable as needed. Drivers should provide mechanism, not policy — e.g. an HDD driver just fetches/stores blocks; a separate program manages the filesystem. A policy-free driver supports async and sync ops, can be opened multiple times, has no extra software layer, and typically ships with a separate user-space program that implements policy.

Kernel responsibilities: create/destroy processes, handle process I/O, schedule processes, build a process's virtual address space, malloc/free memory, maintain the filesystem (ext4, fat, ntfs, ...), device control, networking, applications.

A driver is kernel code controlling hardware (may or may not load at runtime). A module is kernel code added at runtime — may contain a driver, or extend kernel functionality more generally.

insmod — link a module into the running kernel
rmmod — unlink
modprobe — link including dependency resolution

23. Device classes

Character: byte-stream access, open/close/read/write (e.g. /dev/console, /dev/ttyS0); may or may not support seek/mmap but still looks like a file.
Block: hosts a filesystem, transfers on block boundaries (usually ≥512 bytes) at the device level; Linux manages sub-block access transparently (e.g. /dev/sda1 as rootfs).
Network: hardware or software (e.g. loopback) devices handling packets, not bytes/blocks; not accessible as a conventional file — named like eth0 instead, since packet I/O doesn't map well to read()/write().

The kernel filesystem layer maps low-level disk blocks to directories/files independent of the transfer mechanism. Drivers typically encode no security policy (exceptions: interrupt lines, harmful-update checks). A driver can only load against the exact kernel it was compiled for — compiler version, target kernel, processor, and config vars must all match.

24. Kernel space has no memory-management safety net — always free what you allocate, and a segfault can bring down the whole system. Kernel stack is much smaller than user stack (~4KB vs ~2MB for applications) — size buffers accordingly, and floating point is generally unsupported. Async access needs mutex locks for thread safety.

25. Building a module (hello.c → hello.o):

obj-m := hello.o   # Loads our module into the kernel

KERNELDIR ?= /lib/modules/$(shell uname -r)/build
PWD := $(shell pwd)

ifeq ($(KERNELRELEASE),)
# Called from user space — need to invoke the target kernel build
module:
	$(MAKE) -C $(KERNELDIR) M=$(PWD) modules
modules_install:
	$(MAKE) -C $(KERNELDIR) M=$(PWD) modules_install
else
# Called from within the kernel build itself
obj-m := hello.o other_module.o
endif

Invoke with: make -C /path/to/kernel/source M=$(pwd) (/lib/modules lists available kernels; uname -r gives the current version).

26. Makefile variable expansion

A = $(B) world with B = hello → A = "hello world" (= expands at use time)
A := $(B) world with B = hello (set after) → A = " world" (:= expands immediately)
C = wow, C ?= hello, A = $(C) world → A = "wow world" (?= sets a default only if unset)

insmod loads a .ko file after linking against the kernel symbol table; modprobe also resolves dependencies (avoiding "unresolved symbols" failures). lsmod lists currently loaded modules.

27. The static __init function should register kernel facilities (devices, fs, sysfs, proc, ...) and initialize data structures — which must live in allocated memory, not the stack (the init stack disappears after __init completes, since the module loader drops the init code from memory once loading finishes). The exit function unregisters everything in reverse order and frees allocated memory.

For init failure handling, use goto with a dedicated error-handler label per possible failure point:

#include <linux/init.h>
#include <linux/module.h>
MODULE_LICENSE("Dual BSD/GPL");

int __init my_init_func(void) {
	int err;
	err = register_1(ptr1, "wow");
	if (err) goto fail_1;
	err = register_2(ptr2, "dayunm");
	if (err) goto fail_2;
	return 0;

	fail_2: unregister_1(ptr1, "wow");
	fail_1: return err; // propagate the error
}

module_init(my_init_func);
module_exit(my_exit_func);

Register/unregister steps depend on the driver type used. Module parameters: module_param(var, type, permissions) — e.g. S_IRUGO (readable, not changeable), S_IRUGO | S_IWUSR (writable by root).

28. A scull driver is a fake driver for development/learning only (real drivers don't use these):

i. scull0–scull3: default devices shared by all processes (standard R/W IO demo)

ii. scullpipe0–scullpipe3: FIFO drivers; data written by one process is read by another; supports blocking (waits when empty) and non-blocking (returns immediately when empty) IO

iii. scullsingle: only one process can open the device at a time

iv. sculluid: each UID gets a private memory region (multiuser isolation)

v. scullwuid: like sculluid, but other users can read (not write)

vi. scullpriv: each PID gets a private memory region

H) Character Drivers

29. Each device has a major/minor number (ls -l <driver-path> to inspect). Major maps the kernel to the device file (driver); minor distinguishes specific devices handled by that driver.

/dev/null = major 1 (null driver); /dev/tty0 = major 4 (tty driver)
Disk devices (sda–sdp) are numbered minor 0, 16, 32 ... up to 240 — e.g. sda=0, sda1=1, sda5=5, sdb1=17, etc.

30. Registration needs an fops table — file_operations connects driver operations to a device number, so the kernel locates the driver then the specific operation for a read/write request (OOP-style in C, via structs and pointers).

struct file_operations fops = {
	.owner = THIS_MODULE,
	.read = my_read_func,
	.write = my_write_func,
	.open = my_open_func,
};

Other fields: fmode_t f_mode (readable/writable), loff_t f_pos (current r/w position), uint f_flags (O_RDONLY, O_NONBLOCK, O_SYNC), struct file_operations *f_op, void *private_data (driver-allocated memory pointer).

Unregister:

__unregister_chrdev(major_num, baseminor, count, "driver-name");
// baseminor = first minor occupied; count = number of minors after it

Newer registration approach (cdev + fops):

alloc_chrdev_region(&dev_num, 0, 1, "driver-name"); // Allocate device number dev_t
cdev_init(&my_cdev, &fops);                          // Initialize a cdev struct
cdev_add(&my_cdev, dev_num, count);                  // Add cdev to the system
my_class = class_create(THIS_MODULE, "my_class");
device_create(my_class, NULL, dev_num, NULL, "my-device"); // Create /dev entry

dev_num is a typedef packing major/minor — use MAJOR(&dev_num) / MINOR(&dev_num) to extract them. count = number of consecutive minor numbers buffered for this driver. Adding a cdev generates an inode holding permissions, metadata, and a pointer to the cdev.

31. After registration, /proc/devices lists currently allocated devices/drivers, parsed (e.g. via awk) to create /dev entries with mknod — necessary because nodes can't be pre-created under dynamic allocation.

major=$(awk '$2=="module" {print $1}' /proc/devices)
# Wherever field 2 == module name, print field 1 (the major number)

Dynamic device loading steps: insmod the module (inits it) → parse /proc/devices for the major number → mknod with that major number → chown/adjust ownership as needed.

32. Very important — the "everything is a file" model for drivers

Every file (regular, directory, socket, device) has a struct inode with metadata and type. Regular files' inodes point to their data blocks; driver inodes instead store the device number (dev_num) and a pointer to a cdev. The cdev bridges kernel and driver — holding driver object files, owner info, and crucially the fops table defining read/write/open. So open("/dev/device") → kernel checks the inode → sees it's a char device with major/minor N → follows the cdev → uses its fops → calls open.

Kernel memory:

kmalloc(size_t size, int flags); // allocate, size in bytes
kfree(void *ptr);

Kernel debugging via printk, tagged with a level (KERN_EMERG/ALERT/CRIT/ERR/WARNING/NOTICE/INFO/DEBUG, levels 0–7; 1=alert/emerg, 4=warning, 7=debug):

printk(KERN_DEBUG "This var %s", var);

33. Defining open/read/write

i. Open method

Check for device errors
Initialize the driver if this is the first open
Update the f_ops pointer to file_operations
Allocate/set private_data to the file's allocated memory
Connect to the driver's data/params (e.g. a my_device struct)
Signature: int (*open)(struct inode *, struct file *)

To get the device struct pointer from the inode:

struct cdev *my_cdev = inode->i_cdev;
struct my_device *dev = container_of(my_cdev, struct my_device, cdev);
// Since our device struct also holds a cdev pointer, container_of uses
// pointer arithmetic to recover the enclosing my_device struct.

ii. Release method — reverses the open method; deallocates anything allocated into filp->private_data.

iii. Read and write methods — fetch from / write to the device's buffer:

size_t read(struct file *filep, char __user *buff, size_t count, loff_t *pos);
size_t write(struct file *filep, char __user *buff, size_t count, loff_t *pos);

buff is a user-space pointer, inaccessible directly from kernel space (MMU memory protection) — hence copy_to_user()/copy_from_user() (which perform a memcpy across the boundary).

An alternative to structured read/write buffer exchange is ioctl — a more flexible device-control interface (locking, ejecting, reporting, etc.), callable only from outside plain user-space reads (e.g. a Python script), though it has fallen out of favor among developers.

34. Processes and memory layout

A process is a program in execution. For compiled languages (C, Rust, Go), the program is text (compiled binary/assembly) + data (statics/constants); it becomes a process on execution, gaining a memory layout of text, data, heap, and stack. Two Chrome windows are independent processes sharing the same .text (the chrome.exe binary) but with separate heap/stack.

Interpreted languages differ: Python/JS don't compile app.py to an executable — the interpreter binary occupies .text, while the script's code lives in the heap during execution. On launch, text and data go to RAM, with parts of heap/stack cached for speed. The CPU executes the .text binary line by line, tracked via a program-counter register.

Example: LOAD R0 1011 loads register 0 from RAM address 1011; LOAD R1 1012 similarly; ADD R1 R0 — encoded in binary as something like 00 01 01 00, where the first 00 tells the CPU this is an ALU (not memory) operation (via a decoder enabling the ALU vs RAM), the next 01 selects the add circuit (via another decoder), and register values feed into the add circuit to produce the result.

35. Context switching and scheduling

For concurrency, the CPU context-switches between processes. Early approaches were cooperative (programs manually yielded via halts) — insecure, since a runaway loop could crash the system. Pre-emptive scheduling replaced this: predicting (via nice values) how much time to give a process before forcing an interrupt back to the OS.

On switch, the CPU must save the current process's register state so the outgoing process doesn't see/leak it and can resume correctly later — stored in a Process Control Block (PID, state, CPU registers — program counter, general-purpose registers, instruction register, ALU flags, stack pointer, index registers — memory limits, I/O devices, files, parent/child pointers). This PCB sits in the OS's queue for scheduling/preemption. Linux calls this the task_struct — the concept is universal even if each OS represents it slightly differently.

36. Kernel mode vs user mode

Every architecture has an instruction set; many restrict certain instructions to a privileged ("restricted") mode for safety, tracked via a hardware mode bit — this is the kernel mode / user mode split. An application needing hardware access must make a system call, which triggers an interrupt; the OS's interrupt handler runs in kernel mode, which is how a syscall reaches kernel-only instructions.

(Special thanks to Priyanshu Shah for his amazing handwritten notes that have served as the basis for this page)
